In the previous sections Model Quantization and Compilation - Overview and Introduction to PyTorch Model Quantization, we have already provided an overall introduction to the PyTorch model quantization pipeline. Next, this chapter will further walk you through the practical usage flow, covering the complete main path of PyTorch model quantization, from floating-point model transformation, QConfig configuration, Prepare, and Calibration, to QAT, export, fixed-point conversion, compilation, and final verification.

If you would like to experience a minimal closed loop first, we recommend that you read PyTorch Model Quick Start first. If you would like to further explore a basic deployment-side example, you may also refer to the sample we provide in the OE package under the samples/ai_toolchain/horizon_model_train_sample/plugin_basic path.

The overall PyTorch model quantization pipeline is shown below:

#Stage Description

The detailed PyTorch model quantization pipeline includes several steps, including floating-point model transformation, Prepare(include QConfig configuration), Calibration, QAT training, Export / Convert, Compile and quantized.bc / hbm accuracy verification. To help you quickly identify your current stage in practice, understand what should be checked at each stage, and know where to continue when problems arise, we have organized the following table for your reference.

Stage	Input	Main Output / Artifact	Required	Key Checkpoint	Recommended Reference When Requirements Are Not Met
Floating-point Model Transformation	float model	Quantizable float model	Yes	Whether QuantStub / DeQuantStub are inserted properly, whether the preprocessing and postprocessing boundaries are clear, and whether the model is quantization-friendly	Refer to Build Quantization Friendly Model
Prepare	float model + platform strategy + example inputs	fake quantization model, as well as model_check_result.txt, fx_graph.txt, qconfig_dtypes.pt, qconfig_dtypes.pt.py, and qconfig_changelogs.txt	Yes	Whether the model check result, graph structure, and quantization configuration change records are as expected	Refer to Prepare Description, Build QConfig, and Debug Artifacts Guide
Calibration	calib model + calibration data	Model with quantization parameters	Yes	Whether the Calibration accuracy is acceptable, whether the gap from the floating-point baseline is reasonable, and whether the calibration data can represent the real input distribution	If the result is acceptable, you may proceed directly to export and compilation. If the result does not meet requirements, refer to Platform Differences and Precision Tuning Guide
QAT Training	calib model + training data	qat model / checkpoint	Conditionally Required	Whether the accuracy improves after QAT, and whether the training process is stable	Refer to Quantization Aware Training and Precision Tuning Guide
Export / Convert	calib model / qat model	qat.bc / quantized.bc	Yes	Whether the accuracy of quantized.bc meets expectations, and whether the export result is consistent with expectations	Refer to Fixed-point Model Conversion and Deployment Consistency Analysis
Compile	quantized.bc	hbm	Yes	Whether the performance, input / output format, and deployment constraints meet expectations	Refer to Model Compilation and Performance Evaluation and Board Evaluation
Final Verification	quantized.bc / hbm	Model ready for deployment	Yes	Whether the fixed-point model accuracy, board-side result, and deployment consistency meet requirements	Refer to Deployment Consistency Analysis, Debug Artifacts Guide, and Board Evaluation

#Usage Suggestions

Based on practical project experience, we recommend that you understand and use this pipeline in the following way.

1. If your current goal is to verify whether the model can be quantized, exported, compiled, and pass a basic accuracy check, we recommend that you first focus on the minimal closed loop of Floating-point Model Transformation -> QConfig -> Prepare -> Calibration.

2. If the Calibration result already meets your requirements, you do not have to continue with QAT. Instead, you can directly read Fixed-point Model Conversion and Model Compilation and Performance Evaluation to continue with the follow-up process.

3. If the Calibration result does not meet your requirements, we recommend that you first combine Platform Differences, Precision Tuning Guide, and Debug Artifacts Guide to determine whether the main issue comes from quantization configuration, data distribution, model structure, or local operators, and then decide whether to proceed to QAT.

4. If the accuracy is still abnormal after QAT, we recommend that you first refer to the Precision Tuning Guide section for further optimization.

5. If the results of qat.bc / quantized.bc / hbm are inconsistent with expectations, we recommend that you first read Deployment Consistency Analysis for further troubleshooting.

6. No matter which step you are at, when making the final decision on whether the model is ready for deployment, you should always use the accuracy, performance, and deployment results of quantized.bc / hbm as the final criterion, rather than looking only at calib model or qat model.

In the following sections, we will provide detailed explanations of floating-point model transformation, QConfig configuration, Prepare, Calibration, QAT training, fixed-point model conversion, and model compilation and performance evaluation.
